It makes use of mechanical strike and rubbing effect to remove dust, silt, husks, worms
Detail
• It makes use of mechanical strike and rubbing effect to remove dust, silt, husks, worms, wheat beard, microorganisms and other foreign matters adhered to the grain surface, and it could break clods, cinders, insects, shriveled wheat kernels as well as other matters whose strength is lower than that of wheat into small particles and then remove these particles away. Moreover, the remaining sterile lemmas are also separated. In this way, ash content of the unprocessed wheat is cut down, resulting in improved color, reduced ash and sand content of the flour.
• Beating plates are made with special wear-resistant material by precision casting, the service life is greatly prolonged.
• Rotor has gone through dynamic balance test, effectively eradicating imbalance and ensuring steady operation.
| Model | Screening tube Dia(mm) | Screening tube Length(mm) | Capacity(T/H) | Power(kw) | Dimension(mm)(LXWXH) | |
| Softly hit | Heavy hit | |||||
| FDMW40x60 | φ4400 | 600 | 3-5 | 4 | 5.5 | 1700x920x1686 |
| FDMW40x100 | φ 400 | 1000 | 5-8 | 5.5 | 7.5 | 2100x920x1686 |
| FDMW40x150 | φ 400 | 1500 | 8-13 | 7.5 | 11 | 2600x920x1686 |
| FDMW40x150x2 | φ 400 | 1500 | 13-25 | 15 | 22 | 2600x1200x1686 |
